Sanitary grade tank bottom discharge valve，Bottom discharge valve of the tank，Discharge valve

Product Details

Youdaoplaceholder0 Sanitary tank bottom discharge valve ‌ is a type of valve installed at the bottom of a container, mainly used in the food, beverage, pharmaceutical and chemical industries, etc., to ensure no medium retention during discharge and reduce contamination risk. The design features include angular structure, self-discharge function and smooth surface to ensure clean without dead corners

Characteristics

Innovative design without blind spots: Adopting an innovative design without blind spots, it fully meets the high cleanliness requirements, avoids material residue, and ensures the hygiene of the production process.

Multiple specifications are available: The specifications range from 1/2" to 4", and from DN10 to DN100, which can adapt to different tank sizes and flow requirements.

High-quality material guarantee: Made of 316L/1.4404 material, it features outstanding corrosion resistance and hygiene performance, ensuring safe and reliable contact with various media.

Wide temperature adaptability: The operating temperature range is -20℃ to 150℃, and there is also a temperature option of -20℃ to 180℃, allowing for stable operation under different ambient temperatures.

Rich connection standards: Connection standards include threads, clamps, flanges, BSP/BSTP/NPT,DIN,Inch, etc., facilitating connections with various types of tanks and piping systems.

Strong resistance to water hammer: It features resistance to water hammer, effectively protecting the system and reducing the risk of equipment damage caused by water hammer.

Noise-free operation: No noise is generated during operation, creating a quiet and comfortable atmosphere for the working environment.

Reliable sealing performance: Ensures no leakage during the discharge process at the bottom of the tank, enhancing the reliability and safety of the system

Application field

Youdaoplaceholder0 Biopharmaceutical industry ‌ : In the biopharmaceutical process, sanitary tank bottom discharge valves are used to empty and discharge various pressure vessels and storage tanks, ensuring that the tank can be emptied quickly and thoroughly when needed, reducing residue and waste, and improving production efficiency ‌

The design and material selection strictly follow hygiene standards, are easy to clean and disinfect, avoid microbial growth and cross-contamination of products ‌

Youdaoplaceholder0 Food and Beverage industry ‌ : Sanitary bottom discharge valves ensure precise control and safe storage of food materials in dairy, food processing and beverage production. For example, in the dairy industry, these valves ensure the safe storage and discharge of products such as milk; In food processing, they help achieve precise control of various food materials; In beverage production, they provide reliable support for the production of high-quality beverages ‌

Youdaoplaceholder0 Cosmetics industry ‌ : In cosmetics production, sanitary bottom discharge valves are used for fluid control at the bottom of various raw material storage tanks, blending tanks and finished product tanks to ensure purity and quality stability during the cosmetics production process ‌

Youdaoplaceholder0 Chemical Industry ‌ : In the chemical field, sanitary tank bottom discharge valves can handle various chemical media. Their corrosion resistance and sealing performance ensure the stability and safety of the media during transmission ‌

Packing of Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’  is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition
