Product Code : VF--DCC-D98-CU
Body materials: carbon steel, stainless steel, alloy steel
Diameter :2" to 24"(DN50 to DN600)
Pressure range :Class150-300(PN10 - PN50)
Connection methods :RF, RTJ
Operating temperature :-46℃ to +120℃
Operation: Handle, worm gear, electric, pneumatic, etc
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Main feature: The turning center of the butterfly plate is exactly on the centerline of the sealing area between the valve body and the butterfly plate. When closed, the outer cutting sealing surface of the butterfly plate will squeeze out the synthetic rubber valve seat, causing elastic deformation on the valve seat, thereby ensuring the sealing performance of the butterfly valve.
Design features
Design standards :API 609, ASME B16.34, GB/T 12238
It has a small assembly space, is lightweight and easy to maintain
Good sealing effect and long service life
The structure is lightweight and the torque is small
Soft sealing design
Leakage level :ANSI B 16.104 Ⅵ
The turning center of the butterfly plate is exactly on the centerline of the sealing area between the valve body and the butterfly plate. When closed, the outer cutting sealing surface of the butterfly plate will squeeze out the synthetic rubber valve seat, causing elastic deformation on the valve seat, thereby ensuring the sealing performance of the butterfly valve.
