Product Code : VF--QCC-Q203-CU
Product standards: API16D, AP1608, ASTM B16.34
Nominal pressure: 150LB-2500LB
Nominal diameter: DN200-DN1000
Main material: WCB, A105, CF8, F304, CF8M, F316, LCB, LC1, WCC, WC6, WC9, CF3, F304L, CF3M,
F316L,4A,5A,incone1625,Alloy20,Monel,Inocloy,Hastelloy,C5,Ti
Operating temperature: -40℃ to 200℃
Applicable media: water, steam, oil products, natural gas, etc
Connection methods: Flange, welding
Transmission methods: handle, worm gear, pneumatic, electric, hydraulic, pneumatic-hydraulic linkage
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Features
The valve seat assembly adopts adjusting nuts, truly achieving online maintenance and making disassembly and assembly simple and convenient.
2. Patented fireproof structure, reliable fireproof performance;
4. Emergency valve stem seal;
5. Double sealing of contact points;
6. Dual blocking and discharge (D8B);
7. Valve body discharge;
8. Double piston Effect Valve Seat (DlB)
9. Configuration for low-temperature, chlorine gas, oxygen and vacuum environments;
10. Requirements for burial;
11. Extend the valve stem;
12. NACE sulfur resistance requirements
It is mainly applied in industries such as petroleum, chemical engineering, power and metallurgy
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition
