Product Code : VF--ZCC-NL43-CU
Product Introduction
Youdaoplaceholder0 The two-phase steel Angle stop valve is a stop valve with a special structure characterized by a 90-degree connection Angle between the valve body and the valve cover. This design enables the valve to be conveniently installed and maintained in piping systems, especially in situations where space is limited or the flow direction of the medium needs to be changed
Design standards :API, ASME, EN, ISO, JIS, DIN, BS, GB
Connection methods: flange, thread, butt welding, socket welding
Pressure range :CIass150Lb - 2500Lb, 1.0MPa - 42.0MPa, JIS1OK-40K
Size range :NPS3/8*-16 ", DN10-DN400
Drive mode: handwheel, gear, pneumatic, electric, hydraulic device
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Design features of the two-phase steel Angle stop valve:
Full bore or reduced bore
Bolt the valve cover or weld the valve cover
The valve cover and the valve body have a flangeless self-sealing connection structure
The valve seat or the body valve seat can be updated
Conical surface valve control or dry surface valve disc
The main material of the duplex steel Angle stop valve:
Duplex S31803, Super Duplex S32750, Super Duplex S32760
1A, 2A, 3A, 4A, 5A, 6A, 1B, 1C
CD4MCu, CD4MCuN, CD3MCuN, CE8MN, CD6MN, CD3MN, CE3MN, CD3MWCuN
F51, F53, F55, F60
Structural characteristics
The main components of the double-phase steel Angle stop valve include the valve body, valve cover, valve stem, valve seat and sealing ring, etc. These components work together to achieve the opening, closing and sealing functions of the valve. It HAS GOOD sealing PERFORMANCE, when the valve is closed, the sealing ring between the valve body and the valve cover CAN effectively prevent the flow of medium
In addition, Angle stop valves typically use packing seal structure, some advanced designs also use bellows seal to ensure zero leakage of valve stem
Application scenarios
Duplex steel Angle stop valves are widely used in various industrial fields, especially in situations where space is limited or the flow direction of the medium needs to be changed. For example, IN PETROLEUM, chemical, POWER, environmental protection, WATER CONSERVANCY, HEATING, WATER supply and drainage, industry AND MACHINERY AND OTHER FIELDS, the double-phase steel Angle type stop valve CAN PLAY an IMPORTANT ROLE
Its outstanding performance and wide range of application fields make it an indispensable valve type in these fields.
