Sanitary insulated ball valve，Insulated ball valve，Ball valve

Product Details

Youdaoplaceholder0 Sanitary insulated ball valve ‌ is a valve specifically designed for industrial environments with high hygiene requirements. It is mainly used to control fluid flow and ensure the purity and hygiene of the fluid

Characteristics

Multiple specifications: The specifications range from 1" to 4", with diameters from DN25 to DN100, meeting the requirements of different flow rates and pipe sizes.

Temperature adaptation range: The temperature range is from -20℃ to 120℃, suitable for various working environments.

High pressure resistance: The pressure can reach up to 10bar, ensuring stable operation under various working conditions.

High-quality materials: AISI 304 and 316L materials are adopted, which have good corrosion resistance and hygiene performance. The parts in contact with materials are AISI 304/316L, and the other parts are AISI 304.

Unique design: It is designed with a jacketed valve housing to achieve the best heat transfer effect and effectively protect sensitive media that are prone to solidification.

Comply with hygiene standards: The gasket is in accordance with the PTFE FDA 177.1550 standard to ensure safety in contact with the medium.

Flexible installation of handle: Regardless of the flow direction of the liquid, the handle can be installed on the valve body on the side for convenient operation.

Flexible connection: No matter what connection method is used, the total length of the valve will not be changed. The connection methods include threaded, welded, clamps, flanges, DIN, SMS, RJT, FIL, etc., which facilitate connection with different piping systems.

Application field

Food and beverage processing industry

In the food and beverage processing industry, sanitary insulated ball valves are used to control the flow of liquids and gases, ensuring hygiene standards during the production process. For example, on the beverage production line, sanitary insulated ball valve can control the inflow and outflow of raw materials and the delivery of products, prevent cross-contamination, ensure product quality ‌

Pharmaceutical industry

In the pharmaceutical industry, the application of sanitary-grade insulated ball valves is equally important. Due to the extremely high requirements for hygiene conditions in the production of pharmaceuticals, sanitor-grade insulated ball valves are widely used in the transportation of raw materials, the control of reaction vessels, the filtration and filling of products, and other links. These valves not only need to have precise flow control ability, but also must operate stably in high temperature, high pressure or corrosive medium to ensure that the purity and quality of the medicine are not affected ‌

Chemical industry

In the chemical industry, sanitary insulated ball valves are used to control the flow of various chemical media. Due to its strong corrosion resistance, it can operate stably for a long time under harsh working conditions, and therefore is widely used in various chemical production processes ‌

Packing of Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’  is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
