Product Code : VF--NICC-NI12-CU
Model number; PQ40Y, PQ340Y, PQ640Y, PQ940Y
Material; Inconel600, Alloy600, ASTM A494 Gr.CY40
Nominal size; DN40~DN2000, NPS1%~ NPS80
Nominal pressure PN2.5~PN100Class150~Class600
Inconel600 eccentric half ball valve is a kind of nickel based superalloy eccentric half ball valve processed by Inconel600 or Alloy 600 and similar grade ASTM A494 CY40 castings or forgings.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Inconel600 eccentric half ball valve is a kind of nickel-based superalloy eccentric hemispheres processed by Inconel600 or Alloy 600 and similar grades ASTM A494 CY40 castings or forgings, which are the main pressure parts and control parts
The high chromium composition of the steel makes it resistant to sulfides and high temperature oxidation conditions or corrosive solutions. At the same time, the high nickel content makes it resistant to many organic and inorganic chemical attacks and is fundamentally immune to chloride ions and stress corrosion cracking. The valve is designed for eccentric structure, the use of a half ball around the axis of the valve stem rotation 90* to achieve the purpose of opening and closing, when the valve disc is closed, the ball and the sealing surface of the seat between the wedge seal form, can be well cut off the solid particles attached to the sealing surface of the valve ball, so it has a good self-cleaning function, because of these characteristics, so, This product is widely used in high temperature, oxidation and corrosive conditions for the control of solids and other impurities fluid.
Good self-cleaning function, because of these characteristics, this product is widely used in high temperature, oxidation and corrosion conditions, for the control of solids and other impurities fluid
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
