Product Code : VF--ZCC-NI9-CU
Product Introduction
Youdaoplaceholder0 butt-weld titanium gate valve is a type of gate valve made of titanium alloy, mainly used for medium transfer in highly corrosive environments. The core feature is that the oxide film formed by titanium metal in highly corrosive environments has good stability and self-passivation ability, thus resisting strong corrosion under a variety of harsh conditions
The main materials of titanium gate valves include TA1, TA2, TA10, Gr2, Gr3, etc. These materials perform well in highly corrosive environments
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product performance and features
The main feature of titanium gate valves is that they can be used in sulfuric acid, and can withstand sulfuric acid media with a concentration of less than 70%, even above the boiling point. It can withstand various concentrations below 250℃ in acetic acid
In a certain degree of acetic acid medium, it hardly corrodes. It is a unique corrosion-resistant material in various concentrations of alkaline solutions and molten alkaline media. The titanium gate valves produced by Shanghai Yagong have very stable performance
It is fixed and of excellent quality.
Features of titanium gate valves:
Titanium gate valves have a compact structure and reasonable design. They have good rigidity, smooth channels and a small negative flow coefficient.
2. The titanium gate valve adopts flexible graphite and PTFE packing, featuring reliable sealing and easy, flexible operation.
3. The drive methods are divided into manual, electric and gear pneumatic transmission.
4. Structural forms: Elastic wedge single gate plate, rigid wedge single gate plate and double gate plate forms.
Specification parameters
Pressure rating :PN1.0-16.0Mpa
Nominal diameter :DN15-DN1000
Corresponding models :Z11W-16A, Z11W-25A, Z11W-40A, Z11W-64A, Z11W-100A, Z40W-16A, Z40W-25A, Z40W-
40A, Z40W-64A, Z40W-100A, Z41W-16A, Z41W-25A, Z41W-40A, Z41W-64A, Z41W-100A
Applicable medium: Oxidizing corrosive medium.
Youdaoplaceholder0 The application fields of butt-welded titanium gate valve mainly include the following aspects :
Youdaoplaceholder0 Chemical industry : Butt-weld titanium gate valves are widely used in the chemical industry and can withstand various strongly corrosive media, such as chlorine and hydrogen chloride in the chlor-alkali industry, as well as sulfuric acid, acetic acid and other media
Youdaoplaceholder0 Marine engineering : Due to the excellent corrosion resistance and light weight and high strength of titanium alloys, butt-welded titanium gate valves have important applications in Marine engineering and can adapt to the highly corrosive and high-pressure environments in the ocean
Youdaoplaceholder0 Pharmaceutical industry : In the pharmaceutical industry, butt-weld titanium gate valves are often used in environments that require high purity and sterility due to their excellent corrosion resistance and biological safety
Youdaoplaceholder0 Energy and power : In the energy and power sector, butt-weld titanium gate valves can withstand high temperature and high pressure environments and are commonly used in power stations for medium transmission and control
Youdaoplaceholder0 Aerospace : Titanium alloy materials have important applications in the aerospace field. Butt-welded titanium gate valves can adapt to extreme high-temperature and high-pressure environments, ensuring the safe operation of aircraft
Youdaoplaceholder0 Food processing and metallurgy : Butt-weld titanium gate valves are also used in the food processing and metallurgy industries, ensuring the purity of products and the safe operation of production equipment
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
