Sanitary straight-through filter, Straight-through filter, Filter

Product Details

Youdaoplaceholder0 Sanitary straight-through filter ‌ is a device specifically designed to filter solid particles from liquids and is widely used in the pharmaceutical, food, beverage, cosmetic and biopharmaceutical industries. The design feature is straight-through structure, that is, when the liquid flows through the filter, it does not change direction but is filtered directly through the filter element, this design ensures the balance of filtration efficiency and flow rate, and minimizes the retention time of the liquid in the filter to prevent the accumulation of contaminants ‌

Characteristics

Multiple specifications are available

The specifications range from DN25 to DN100/1" to 4", which can meet the needs of production equipment and pipeline systems of different scales. Whether it is a small cosmetics production line or a large food processing plant or a pharmaceutical enterprise, a suitable size can be found.

Adapt to different temperatures

It has a wide operating temperature range, from -10℃ to +120℃ (EPDM), which can meet the temperature requirements of most conventional production environments. At the same time, it can also withstand short-term high temperatures (+140℃, SIP for 30 minutes), meeting the requirements of special disinfection processes.

High pressure resistance performance

The maximum working pressure can reach 10bar/145PSI, and it can operate stably in high-pressure pipeline systems, ensuring that the filtration effect is not affected by pressure changes.

Diverse connection methods

It offers multiple connection methods such as clamps, threads, and welding, and complies with standards like DIN, SMS, RJT, IDF, and 3A, facilitating connection with various pipes and equipment and adapting to different installation scenarios.

Fine filtration accuracy

The mesh size ranges from 0.5mm to 2.0mm, and the screen mesh count is from 30 mesh to 300 mesh. According to different filtration requirements, the appropriate filtration precision can be selected to effectively intercept particle impurities of different sizes.

High-quality gasket material

The gaskets are made of materials such as Silicon MVQ and FPM, which have good sealing performance and corrosion resistance, ensuring that the filter can maintain a reliable seal in different working environments and prevent leakage.

Application field

Youdaoplaceholder0 Food industry ‌ : Sanitary straight-through filters have extensive applications in the food industry. They are commonly used for clarification filtration of liquids such as juice, beer, wine, etc, to ensure the purity and safety of the product ‌

In addition, they can be used for the purification of dairy products and food additives, further ensuring the hygiene standards of products ‌

Youdaoplaceholder0 Pharmaceutical industry ‌ : In the pharmaceutical industry, sanitary straight-through filters are used for terminal filtration of injections, oral liquids, biological products, etc., to ensure that the products are free of bacteria, viruses and other microorganisms and meet strict quality control requirements ‌

They are also often used to prepare perfuses, infusions and drug injections, etc., to ensure the safety and efficacy of drugs ‌

Youdaoplaceholder0 Cosmetics and personal care products ‌ : Sanitary straight-through filters are also used in the production of cosmetics and personal care products. They can ensure that the finished product is free of any impurities that may affect quality, guaranteeing the quality and safety of the product ‌

Youdaoplaceholder0 Other industries ‌ : In addition, sanitary straight-through filters are also used in environmental protection, biochemical water treatment and other fields to filter out particles and bacteria in liquids, ensuring the purity and safety of the treatment process ‌

Packing of Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’  is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition
