Product Code : VF--ZCC-WS39-CU
Sanitary pressure reducing valve
Product diameter: DN25-DN80
Product pressure: 10bar
Product material: 304/316L
Connection type: Clamp, welding, thread,3A BPE DIN SMS IDF ISO
Product sealing: EPDM, FPM, HNBR
Structural type:
Drive mode: Automatic
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Details
Youdaoplaceholder0 Sanitary pressure reducing valve is a type of pressure reducing valve specifically designed to meet high hygiene standards and is widely used in industries such as food, medicine and biotechnology. Its main features are the use of food-grade materials, a smooth surface, easy to clean and disinfect, effectively preventing bacterial growth and ensuring the safety and hygiene of the product
Characteristics
Multiple specifications: Sizes range from 1" to 3", that is, DN25 to DN80, which can meet the demands of production on different scales.
Wide pressure range: The nominal pressure is PN2.5-10, the inlet pressure can reach 8bar, and the outlet pressure can be adjusted between 0.3-5bar to meet the requirements of different working conditions.
High-efficiency flow control: With a Kv value ranging from 4 to 70m³/h, it can precisely control the fluid flow.
High-temperature resistance: It can operate stably at a maximum temperature of 180℃ and is suitable for various high-temperature working conditions.
Applicable to multiple media: Suitable for different media such as steam, liquid and gas, with strong versatility.
Flexible connection methods: Clamping, threading, welding, flange and other connection methods can be selected, which is convenient for connection with different pipeline systems.
Iii. Advantages
Precise pressure control: The proportional control valve design featuring double-seat diaphragm control and spring loading can precisely control the outlet pressure, ensuring stable pressure during the production process and enhancing product quality and production efficiency.
Easy to operate and maintain: The operation is simple and convenient, without the need for complex pneumatic or electrical control components, reducing the operation difficulty and maintenance cost.
Hygienic and reliable: As a sanitary pressure reducing valve, it complies with the hygiene standards of the food and beverage, pharmaceutical and other industries. It is made of high-quality materials to ensure the hygiene and safety of the product and prevent contamination.
Multiple specifications and connection methods: It offers a variety of specifications and connection methods to meet the needs of different users and has strong adaptability.
Application field
The sanitary pressure reducing valves produced are mainly applied in industries with strict hygiene requirements such as food and beverage, brewing, medicine, and chemical engineering. This is a highly easy-to-operate pressure control valve that can control the pressure after the valve without pneumatic or electrical control components, providing precise pressure control for the production processes in these industries. At the same time, it is easy to install and maintain, ensuring the stable progress of production.
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
