Product Code : VF--TJCC-TJ4-CU
This series of products standard type, regulation cut type, bellows sealed type, jacket insulation type and other varieties. Nominal pressure grades of products are PN10, 16, 40, 64; Valve body diameter range DN20 ~ 200. Suitable for a variety of grades from -200 ° C to 560 ° C. The leakage standard is class IV or Class VI. The flow characteristics are linear or equal percentage. A wide variety of specifications to choose from.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
The straight-through regulating valve is suitable for the workplace where the pressure difference between the front and back of the small leakage valve is not large. Pneumatic diaphragm through single-seat regulating valve adopts top guide structure, equipped with multi-spring actuator. It has the advantages of compact structure, light weight, sensitive action, S-streamline filling channel, small pressure drop loss, large valve capacity, accurate flow characteristics, convenient disassembly and so on. Widely used in accurate control of gas, liquid and other media, process parameters such as pressure, flow, temperature, liquid level to maintain a given value. This series of products standard type, regulation cut type, bellows sealed type, jacket insulation type and other varieties
The straight-through regulating valve is suitable for the workplace where the pressure difference between the front and back of the small leakage valve is not large
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 2022 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
