Product Code : VF--DCC-D96-CU
Size: 1-1/2"-84"(DN40 - DN2100)
Pressure limit: German standard PN10/16, American standard Class 125/150
Valve body material: cast iron, ductile iron, stainless steel CF8M or carbon steel WCB
Valve seat material: Ethylene propylene diene monomer (EPDM) rubber, nitrile rubber (NBR), fluorine rubber (ITON), or polytetrafluoroethylene (PTFE)
Valve disc material: ductile iron, stainless steel 316, bronze
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Structural length specification: ISO5752
2. Installation platform with ISO5211 flange
3. Flange requirements: American standard ANSI125/150,BSTableE, Japanese standard JIS10K, German standard DINPN10,DINPN16
4. All the clamping type fixing holes are convenient for installation
5. Quality Assurance: ISO9001,PED97/23/EC
6. Quota :1 -1/2" to 12":228PSI(16 bar)14" to 24":150 psi (10 bar)
7. Selection: Rod, gear, pneumatic, electric operation
8. Scope of application: water treatment, air, oil, powder, gas, etc
Scope of application: water treatment, air, oil, powder, gas, etc
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
