Product Code :
Jacket ball valve is suitable for pipeline fluid viscosity is high, easy to solidify the petrochemical, chemical industry, the use of one-piece, full jacket structure, effectively prevent the condensation of the medium in the tube and maintain the temperature of high viscosity fluid, to avoid fluid condensation in the atmospheric environment temperature.
Caliber range: 1/2""~8""(DN15~DN200)
Pressure Rating: ASME CLASS 150(PN16)
Main material: carbon steel, stainless steel, alloy steel and duplex steel
Connection type: flange end
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
Benefits
Uni-body design inherently avoids problem of body joint leak
Fully welded face to face jacket ensures maximum heat input
Long cycle life
Easy to maintain
Single source responsibility with reliable Neles actuators, switches, and controllers
Compliance with industry standards
Features
Unique low torque seat design provides bubble-tight shut-off through pressure and temperature cycles
mounting pad for direct mounting of handle, gear operator, manual override, or actuator
Internal entry blow-out proof stem design
Live-loaded spring stem seal provides long cycle life and low emissions with minimal maintenance
An extremely tight fit drive between the stem and ball ensures accurate and repeatable shut-off and control
Anti-static grounding between ball and stem as well as stem and body
Every valve is factory tested, serialised & quality tagged prior to shipment
Applications
Chemical and petrochemicals
Pulp & paper
Food and beverage
Pharmaceutical
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 2022 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
