Product Code : VF--QCC-Q186-CU
Valve body material: carbon steel, stainless steel, alloy steel, duplex stainless steel
Caliber :16" - 60"
Pressure :Class150-1500
Connection: RF, RTJ, BW
Design temperature :-29℃ to +200℃
Operation: Electric, pneumatic, electro-hydraulic linkage.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
This type of ball valve adopts a three-piece valve body and a double floating valve seat design. When the pressure driving the valve seat on one side increases, the valve seat can closely adhere to the spherical surface for sealing. In short, when the pressure drops, the valve seat will loosen the spherical surface. This type of valve is equipped with a floating valve seat and sealing ring, which enables the valve to be opened and closed easily by applying pressure. Even for the largest valve, the opening and closing torque is very light and easy to control. Therefore, this type of valve is particularly suitable for the front end of the turbine in a hydropower station as a valve for opening and closing the water gate.
Design features
Simple design, tight sealing and high stability
The floating valve seat is equipped with a water pressure and oil pressure system
Low-density packing
The drive shaft is installed horizontally on the side
Valve stem anti-blowout design
The controllability of the valve seat
This type of ball valve adopts a three-piece valve body and a double floating valve seat design. When the pressure driving the valve seat on one side increases, the valve seat can closely adhere to the spherical surface for sealing. In short, when the pressure drops, the valve seat will loosen the spherical surface. This type of valve is equipped with a floating valve seat and sealing ring, which enables the valve to be opened and closed easily by applying pressure. Even for the largest valve, the opening and closing torque is very light and easy to control. Therefore, this type of valve is particularly suitable for the front end of the turbine in a hydropower station as a valve for opening and closing the water gate.
Design features
Simple design, tight sealing and high stability
The floating valve seat is equipped with a water pressure and oil pressure system
Low-density packing
The drive shaft is installed horizontally on the side
Valve stem anti-blowout design
The controllability of the valve seat
